SAA

Primary Technical Characteristics

  Elecreical Performance  Material and Mechanical Performance
  Characteristic Impedance   50Ω     Center Contact   Pin   Beryllium Copper   Gold Plating
  Frequency Range   0~4.8GHz     Socket   Beryllium Copper   Gold Plating
  Rated Voltage   250V rms     Body and Other Metal Parts   Brass/Stainless Steel   Gold plating / Passivation
  Dielectric Strength Voltage   750V rms     Elastic Part     Beryllium Copper   Gold Plating
  VSWR   ≤1.25   Straight   Insulator     PTPE
  ≤1.40   Angled   Seal Ring     Silicon Rubber
  Contact Resistance   ≤10mΩ   Center Contact   Temperature Range     -65℃ ~+165℃
  ≤6.0mΩ   Outer Contact   Durability     500 times
  Insulation Resistance   ≥1000MΩ
  Insertion Loss   ≤0.06√f(GHz)dB



Model

  Part Number  Cable Type  Notes
  SAA-JW202   SFF-50-2-51
