Feature
• Good mechanical and environmental performance.
• Flame retardance meets relevant standards.
• Suitable for indoor cabling and lead-into-building cable.
• Suitable for pigtail fiber and jumper wire.
• For optical connection in optical communication machine room, optical distribution frame, optical device, equipment, etc.
• Jacket can be made of flame retardant PVC, LSZH flame retardant polyolefin or other agreed materials.
• Customized design is available.
Technical Parameter
| Fiber Count | Cable Size (mm) | Cable Weight (kg/km) | Tensile Load (N) | Crush Load (N/100mm) | Temperature Range (℃) |
||
|---|---|---|---|---|---|---|---|
| Long-term | Short-term | Long-term | Short-term | ||||
| 4 | 1.0×4.3 | 8 | 130 | 300 | 200 | 500 | -20~+60 |
| 6 | 1.0×4.8 | 10 | 130 | 300 | 200 | 500 | |
| 8 | 1.0×5.4 | 12 | 130 | 300 | 200 | 500 | |
| 12 | 1.0×6.5 | 14 | 130 | 300 | 200 | 500 | |
Note：1. Minimum bend radius: for B1.1, B1.3, B4 single mode fiber and multi-mode fiber, 20H under dynamic bending and
10H under static bending; for B6 fiber, 10H (dynamic) and 5H (static). (H is the minor axis height of flat cable.)
2. All the data in the table are for reference and subject to change without notification.
