Indoor Communication Optical Cable

<Upper layer

Simplex/Duplex Round More Products

Feature

• Soft, flexible, easy to handle.

• Suitable for pigtail fiber and jumper wire.

• Suitable for optical connection in optical communication machine room, optical distribution frame, optical device, equipment, etc.

• Good mechanical and environmental performance.

• Excellent pressure, tensile, bending and flame resistance property.

• Anti-rodent.

• Jacket can be made of flame retardant PVC, LSZH flame retardant polyolefin, TPU or other agreed materials.

• Customized design is available.

Technical Parameter

Fiber Count	Cable Size (mm)	Cable Weight (kg/km)	Tensile Load (N)		Crush Load (N/100mm)		Temperature Range (℃)
Fiber Count	Cable Size (mm)	Cable Weight (kg/km)	Long-term	Short-term	Long-term	Short-term	Temperature Range (℃)
1	3.0	17	150	300	1500	4000	-20~+60
2	3.2	20	150	300	1500	4000	-20~+60

Note: 1. Minimum bend radius: for B1.1, B1.3, B4 single mode fiber and multi-mode fiber, 20D under dynamic bending and 10D

under static bending; for B6 fiber, 10D (dynamic) and 5D (static). (D is overall diameter of round cable)

2． All the data in the table are for reference and subject to change without notification
