Feature
• Soft, flexible, easy to handle.
• Suitable for pigtail fiber and jumper wire.
• Suitable for optical connection in optical communication machine room, optical distribution frame, optical device, equipment, etc.
• Good mechanical and environmental performance.
• Excellent pressure, tensile, bending and flame resistance property.
• Anti-rodent.
• Jacket can be made of flame retardant PVC, LSZH flame retardant polyolefin, TPU or other agreed materials.
• Customized design is available.
Technical Parameter
| Fiber Count | Cable Size (mm) | Cable Weight (kg/km) | Tensile Load (N) | Crush Load (N/100mm) | 适用温度范围 (℃) |
||
|---|---|---|---|---|---|---|---|
| Long-term | Short-term | Long-term | Short-term | ||||
| 4 | 6.5 | 65 | 300 | 600 | 1500 | 4000 | -20~+60 |
| 6 | 6.5 | 65 | 300 | 600 | 1500 | 4000 | |
| 8 | 7.5 | 75 | 350 | 700 | 1500 | 4000 | |
| 12 | 8.0 | 85 | 400 | 800 | 1500 | 4000 | |
Note: 1. Minimum bend radius: for B1.1, B1.3, B4 single mode fiber and multi-mode fiber, 20D under dynamic bending and 10D
under static bending; for B6 fiber, 10D (dynamic) and 5D (static). (D is overall diameter of round cable)
2. The data of cable size and weight are calculated according to ф0.9 tight buffered fiber.
3． All the data in the table are for reference and subject to change without notification
